PRECISION DRILL POINT INSPECTION SYSTEM
#9600 Digital Drill Point Web Thickness Gage
For Measuring Self Drilling / Tapping Screw Drill Point Geometry
ISO, DIN, IFI and JIS Standards
The Universal Punch #9600 Digital Drill Point Web Thickness Gage provides a fast, accurate, and repeatable method for measuring the web thickness of drill points on self drilling fasteners.
Specifically designed for use with mechanical or digital indicators, this inspection gage enables manufacturers to verify drill point geometry after forming or sharpening processes.
Maintaining proper web thickness is critical for ensuring:
• Controlled feed pressure
• Proper chip evacuation
• Improved drill performance
• Reduced breakage and tool failure
Portable yet durable, the #9600 system is designed for use in demanding manufacturing and quality inspection environments.
Standard protected precision stroke bearings and repeatable spring force ensure consistent measurement accuracy throughout the entire range of travel.
Measurement Application
Drill Point Web Thickness
Center Cutting Geometry
Feed Pressure Performance
Drill Point Structural Integrity
Key Technical Benefits
Digital Measurement Capability
Reduces operator interpretation and enables faster inspection of drill point geometry.
Repeatable Spring Force
Provides consistent measurement throughout the full stroke range.
Protected Precision Bearings
Designed for harsh shop floor inspection environments.
Portable Inspection Fixture
Ideal for inspection room or at-machine verification.
Improves Tool Life
Ensures web thickness does not cause excessive feed pressure or premature failure.
Compatible with SPC Systems
Supports digital indicators and output for statistical process control.
Available Components
Part Number
Description
9600-01
Web Thickness Gage
9600-02
Base Plate and Mounting Post
9600-05
Carbide Sharp Points
9600-31
Carbide Ball Points .031" / 0.78mm
9600-46
Carbide Ball Points .046" / 1.16mm
9600-62
Carbide Ball Points .062" / 1.57mm
600010
Dial Indicator .500" Range / .001" Grad
600020
Dial Indicator 12mm Range
543683
Digital Indicator for SPC .0005" / 0.01mm
905338
SPC Connecting Cable
264503
DPHIS Miniprocessor Recorder
System Performance
Proper web thickness is critical to maintaining drill performance and preventing failure in self drilling fasteners. Excessively thick drill webs may result in:
- Increased feed pressure
- Poor chip evacuation
- Tool breakage
- Reduced drilling efficiency
Conversely, excessively thin webs may weaken the drill point structure, increasing susceptibility to premature failure. The #9600 Digital Web Thickness Gage provides manufacturers with the ability to inspect and control drill point geometry to ensure consistent performance across production lots.
What’s Included
- Web Thickness Gage Assembly
- Base Plate
- Mounting Post
- Carbide Measuring Points
- Indicator Mounting System
