Precision Radial Geometry Inspection for Fasteners and Cylindrical Components
Concentricity & Runout Measurement Systems
Universal Fastener Gages designs advanced concentricity and runout measurement systems for verifying radial alignment, axis integrity, and rotational consistency in fasteners and precision components. Engineered for repeatability and production reliability, our systems support aerospace, medical, and high-performance manufacturing environments.
Critical Radial Geometry Verification
Concentricity and runout directly impact assembly performance, rotational balance, and structural integrity. Our systems verify shaft-to-thread alignment, head-to-shank concentricity, and total indicator runout (TIR) to ensure components meet strict dimensional tolerances.
These inspection systems are engineered for consistent operator use while maintaining high-resolution measurement accuracy.
Product Families
SYSTEM
Universal Punch Concentricity Gage System
Complete concentricity inspection platform designed to measure alignment between critical fastener features including head, shank, and thread axis.
PLATFORM
9200 Series Wobble Gage & Gaging Fixture
Precision wobble and runout verification system engineered for production inspection and quality control environments.
Measurement Functions Within This System
Total Indicator Runout (TIR)
Thread-to-Axis Alignment
Radial Deviation Measurement
High-Resolution Dial or Digital Options
Head-to-Shank Concentricity
Shaft Straightness Verification
Rotational Consistency Testing
Custom Fixture Adaptability
Designed for Precision Manufacturing
Our concentricity and runout systems are used in applications where radial alignment is critical to assembly performance and long-term durability.
Industries Served:
Aerospace Fastener Manufacturing
Medical Device Components
Automotive Powertrain Components
Defense and High-Performance Hardware
Precision Machined Components
Engineered for Accuracy and Stability
Manufactured in USA
Made in USA
High-precision indicator integration
NIST Traceable
Calibration documentation available
Compatible with SPC data collection systems
SPC Compatible
Rigid base construction for measurement stability
Repeatable fixturing systems
ANSI / ISO Compliant
Designed for production and lab environments
Which Runout System Do I Need?
If verifying head-to-shank alignment
→ Concentricity Gage System
If requiring custom fixture support
→ Concentricity Gage System
If measuring total indicator runout
→ 9200 Series Wobble Gage
If performing high-volume quality checks
→ 9200 Series
Quality Assurance & Measurement Integrity
All Universal Fastener Gages concentricity and runout systems are engineered with precision-ground contact points and stable fixturing platforms. Calibration documentation and NIST traceability are available upon request to support regulated manufacturing environments.
